What kind of ventilation conditions should be provided for the generator set placement environment?

1. The diesel generator set should be installed in the machine room with good ventilation, clean environment, and close to the main electrical equipment and power distribution room. The computer room should be equipped with exhaust facilities. The machine room of the closed diesel generator set generally does not need forced ventilation, and the air can be exhausted to the outside through the fan of the unit to promote the air convection in the machine room. In the machine room of the open diesel generator set, the fan can be set up for forced ventilation if necessary. In a place far away from the unit, use a fan and a large-diameter air inlet pipe to introduce outdoor air into the machine room. The air outlet of the inlet pipe should be as low as possible, so that the introduced air can pass through the heat dissipation part of the generator set. The exhaust fan should be installed at the inner height, so that the high-temperature updraft can be discharged outdoors in time.

2. Achieve the optimal combination of ventilation and dustproof. There must be enough fresh air in the engine room, otherwise dirty air will reduce the power of the diesel engine. Dust can destroy the insulation between the engine rotors and burn the generator set. If the ventilation is good, the moisture-proof performance will inevitably be appropriately reduced. If you think too much about dust, it will affect the ventilation of the generator room. The two seemingly contradictory aspects require the generator room designer to calculate and coordinate according to the actual situation to achieve the optimal combination.

3. The space layout should be reasonable. The distance between the units and from the outer profile of the unit to the wall should meet the needs of handling equipment, local operation, maintenance and overhaul or arrangement of auxiliary equipment.

4. Equipped with fire extinguishing device, safe and guaranteed: dry powder fire extinguisher. including hand-held and cart-style; Automatic fire extinguishing device for dry powder. The independent hanging type can be used, and when no one is on duty, it can automatically start extinguishing the fire as soon as a fire occurs.
