200kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ200GF 输出功率 Power Output 150kW/187.5kVA 输出电压 Voltage Output 430V/230V 输出电流 Current Output 360A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2100 (KG) 开架尺寸 Open type size 2950*884*1494（LWH mm） 静音箱机组/重量 Static speaker unit weight 2600 (KG) 静音尺寸： Silent type size: 3800*1300*1950（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP10D238E200 / WP10D264E200 WP7D240E310 / WP7D264E310 WP10D264E350 品牌 Brand WC 排量 Displacement 7.47 (L) / 9.73 (L) 柴油机额定功率 Diesel engine rated power 216kW-240kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 105*130 (mm) / / 压缩比 Compression Ratio 17.0:1/17.5:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 24(L) 备用功率 Standby power 238(kW)-264 (kW) 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-200 品牌 Brand Huaquan 额定功率 Rated Power 200kW/250kVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the nationa
30kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ30GF 输出功率 Power Output 30kW/37.5kVA 输出电压 Voltage Output 400V/230V 输出电流 Current Output 54A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 650KG 开架尺寸 Open type size 1800*750*1150（LWH mm） 静音箱机组/重量 Static speaker unit weight 950KG 静音尺寸： Silent type size: 2550*1100*1570（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP2.3D40E200/ WP3.2D36E310 / WP3.2D44E310 品牌 Brand WC 排量 Displacement 2.29( L) -3.17 ( L) 柴油机额定功率 Diesel engine rated power 33kW-36.8kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（full load） 195g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 8992(mm) /98105(mm) 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 8.5(L)-9(L) 备用功率 Standby power 36kW-44kW 调速方式 Governor Type: Electronic regulatorl/电子调速 ECU central conrtol unit/电控 电机型号： Alternator Secifications Model: HQF-30 品牌 Brand Huaquan 额定功率 Rated Power 30kW/37.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 4. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three emission standards ,energy saving. 5. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protectio
300kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ300GF 输出功率 Power Output 300kW/375kVA 输出电压 Voltage Output 430V/230V 输出电流 Current Output 540A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2400 (KG) 开架尺寸 Open type size 3100*950*1520（LWH mm） 静音箱机组/重量 Static speaker unit weight 3400 (KG) 静音尺寸： Silent type size: 4100*1500*2100（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP12D353E200 / WP13D385E200 WP13D385E310 品牌 Brand WC 排量 Displacement 11.6 (L)/12.5 (L) 柴油机额定功率 Diesel engine rated power 288kW-360kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 126*155 (mm) / 127*165 (mm) 压缩比 Compression Ratio 15.0:1/16.0:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 36(L) 备用功率 Standby power 353(kW)-385(kW) 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-300 品牌 Brand Huaquan 额定功率 Rated Power 300kW/375kVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three emission sta
50kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ50GF 输出功率 Power Output 50kW/62.5kVA 输出电压 Voltage Output 400V/230V 输出电流 Current Output 90A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 800 (KG) 开架尺寸 Open type size 2100*790*1241（LWH mm） 静音箱机组/重量 Static speaker unit weight 1100 (KG) 静音尺寸： Silent type size: 2550*1100*1570（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP4.1D66E200/ WP4.1D66E310 品牌 Brand WC 排量 Displacement 4.09（ L ） 柴油机额定功率 Diesel engine rated power 60kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（full load） 195g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 105118 mm 压缩比 Compression Ratio 17.5:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 13（ L ） 备用功率 Standby power 66kW 调速方式 Governor Type: Electronic regulatorl/电子调速 ECU central control unit/电控 电机型号： Alternator Secifications Model: HQF-50 品牌 Brand Huaquan 额定功率 Rated Power 50kW/62.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 4. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three emission standards ,energy saving. 5. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 6.Camel ba
200kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ200GF 输出功率 Power Output 200kW/250kVA 输出电压 Voltage Output 380V 输出电流 Current Output 360A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2200KG 开架尺寸 Open type size 2600*950*1571（LWH mm） 静音箱机组/重量 Static speaker unit weight 2700KG 静音尺寸： Silent type size: 3800*1300*1950（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model 6LTAA8.9-G2/6LTAA8.9-G3/L9CS4-GT2 6CTAA8.3-G9/6LTAA9.5-G3/QSL8.9-G2 QSB6.7-G31/QSL8.9-G3/QSL8.9-G4 QSL8.9-G34/L9CS4-GT1/QSM11-G1 NT855-GA/NT855-G1/QSNT-G6 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 206-250kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 114*145mm/ 116.5*144.5mm/140*152mm 压缩比 Compression Ratio 16.1:1/16.4:1/16.6:1/16.7:1/17.3:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 19.5-32.4L 备用功率 Standby power 240-265kW 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-200 品牌 Brand Huaquan 额定功率 Rated Power 200KW/250KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of prec
120kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ120GF 输出功率 Power Output 120kW/150kVA 输出电压 Voltage Output 380V 输出电流 Current Output 216A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1200KG 开架尺寸 Open type size 2380*880*1300（LWH mm） 静音箱机组/重量 Static speaker unit weight 1800KG 静音尺寸： Silent type size: 3200*1100*1770（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） QSB5.9-G3 发动机型号： Engine Model B5.9CS4-GT1/6BTAA5.9-G2/6BTAA5.9-G12 QSB5.9-G3/QSB5.9-G31 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 129-140kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 102*120mm/ 107*124mm 压缩比 Compression Ratio 17.3:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 16-16.4L 备用功率 Standby power 130-150kW 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-120 品牌 Brand Huaquan 额定功率 Rated Power 120KW/150KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three emission standards ,energy saving.
150kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ150GF 输出功率 Power Output 150kW/187.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 270A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1500KG 开架尺寸 Open type size 2400*880*1443（LWH mm） 静音箱机组/重量 Static speaker unit weight 1900KG 静音尺寸： Silent type size: 3200*1100*1770（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） B6.7CS4-GT2 发动机型号： Engine Model 6CTA8.3-G1/6CTA8.3-G2/QSB5.9-G33 QSB6.7-G3/QSB6.7-G4/QSB6.7-G32 B6.7CS4-GT2 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 151-173kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 102*120mm/ 107*124mm/114*135mm 压缩比 Compression Ratio 17.3:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 16-28L 备用功率 Standby power 175-185kW 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-150 品牌 Brand Huaquan 额定功率 Rated Power 150KW/187.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three em
50kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ50GF 输出功率 Power Output 50kW/62.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 90A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 850KG 开架尺寸 Open type size 1950*790*1500（LWH mm） 静音箱机组/重量 Static speaker unit weight 1150KG 静音尺寸： Silent type size: 2400*940*1570（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model 4BTA3.9-G2/B3.9CS4-GT3/QSB3.9-G35 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 50-70kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（100％Load） 195g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 102*120mm 压缩比 Compression Ratio 17.3:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 10.9L 备用功率 Standby power 55-80KW 调速方式 Governor Type: Electric control/电子调速 电机型号： Alternator Secifications Model: HQF-50 品牌 Brand Huaquan 额定功率 Rated Power 50KW/62.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 6. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loos
150kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ150GF 输出功率 Power Output 150kW/187.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 270A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1600KG 开架尺寸 Open type size 2600*850*1600（LWH mm） 静音箱机组/重量 Static speaker unit weight 2100KG 静音尺寸： Silent type size: 3200*1100*1770（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model HD-150L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 165KW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke / 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 180KW 调速方式 Governor Type: Electric control/电子调速 电机型号： Alternator Secifications Model: HQF-150 品牌 Brand Huaquan 额定功率 Rated Power 150KW/187.50KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 6. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and r
200kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ200GF 输出功率 Power Output 200kW/250kVA 输出电压 Voltage Output 380V 输出电流 Current Output 360A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight / 开架尺寸 Open type size / 静音箱机组/重量 Static speaker unit weight / 静音尺寸： Silent type size: / 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model HD-200L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 235KW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke / 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 268KW 调速方式 Governor Type: Electric control/电子调速 电机型号： Alternator Secifications Model: HQF-200 品牌 Brand Huaquan 额定功率 Rated Power 200KW/250KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 6. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 7. Pure copper brushless
50Kw Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ50GF 输出功率 Power Output 50kW/62.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 90A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 800KG 开架尺寸 Open type size 1800*750*1300（LWH mm） 静音箱机组/重量 Static speaker unit weight 1200KG 静音尺寸： Silent type size: 2550*1100*1570（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model HD-50L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 56KW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 205g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 105125 mm 压缩比 Compression Ratio 19.0:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 62KW 调速方式 Governor Type: machine control/机械调速 电机型号： Alternator Secifications Model: HQF-50 品牌 Brand Huaquan 额定功率 Rated Power 50KW/62.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminating t
30Kw Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ30GF 输出功率 Power Output 30KW/37.5kva 输出电压 Voltage Output 380V 输出电流 Current Output 54A 额定频率 Rated Frequency 60Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 700KG 开架尺寸 Open type size 1750*750*1300（LWH mm） 静音箱机组/重量 Static speaker unit weight 1000KG 静音尺寸： Silent type size: 2550*1100*1570（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model HD-30L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 30.1KW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 205g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 100115 mm 压缩比 Compression Ratio 19.0:1 启动方式 Starting System DC12V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 33KW 调速方式 Governor Type: machine control/机械调速 电机型号： Alternator Secifications Model: HQF-30 品牌 Brand Huaquan 额定功率 Rated Power 30KW/37.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminating
