Technical parameters of diesel generator set Generator set model：HQ600GF Steady state voltage adjustment rate (%): 1 Generator power:600kW/750kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:1080A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:4050*1540*1920 （L*W*H mm） Diesel generator fuel consumption (100% load):210g/kWh Diesel generator weight:5200kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Weichai engine Cooling method: Closed water-cooling Diesel engines model: 12M26D748E200 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 150*150 mm Intake method: Natural inhalation Compression ratio: 15：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-600 Wiring mode：Three-phase four-wire, Y-connection Generator power: 600kW/750kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Daily fuel tank、
A Technical parameters of diesel generator set Generator set model：HQ1000GF Steady state voltage adjustment rate (%): 1 Generator power:1000kW/1250kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:1800A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:5800*1600*2200 （L*W*H mm） Diesel generator fuel consumption (100% load):209g/kWh Diesel generator weight:8850kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Yuchai diesel engine Cooling method: Closed water-cooling Diesel engines model: YC6C1520L-D31 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 200*210mm Intake method: Natural inhalation Compression ratio: 13.5：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-1000 Wiring mode：Three-phase four-wire, Y-connection Generator power: 1000kW/1250kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、
A Technical parameters of diesel generator set Generator set model：HQ800GF Steady state voltage adjustment rate (%): 1 Generator power:800kW/1000kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:1440A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:4200*1500*1850 （L*W*H mm） Diesel generator fuel consumption (100% load):209g/kWh Diesel generator weight:4850kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Yuchai diesel engine Cooling method: Closed water-cooling Diesel engines model: YC6C1320L-D31 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 200*210mm Intake method: Natural inhalation Compression ratio: 14.5：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-800 Wiring mode：Three-phase four-wire, Y-connection Generator power: 800kW/1000kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Dail
Technical parameters of diesel generator set Generator set model：HQ600GF Steady state voltage adjustment rate (%): 1 Generator power:600kW/750kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:1080A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:4200*1500*1880 （L*W*H mm） Diesel generator fuel consumption (100% load):205g/kWh Diesel generator weight:4650kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Yuchai diesel engine Cooling method: Closed water-cooling Diesel engines model: YC6TD900-D31 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 200*210mm Intake method: Natural inhalation Compression ratio: 14.5：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-600 Wiring mode：Three-phase four-wire, Y-connection Generator power: 600kW/750kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Daily fue
Technical parameters of diesel generator set Generator set model：HQ1200GF Steady state voltage adjustment rate (%): 1 Generator power:1200kW/1500kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:2160A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:5800*1600*2200 （L*W*H mm） Diesel generator fuel consumption (100% load):209g/kWh Diesel generator weight:9850kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Yuchai diesel engine Cooling method: Closed water-cooling Diesel engines model: YC12VC2070L-D20 Oil supply method: direct injection Engine cylinder number: 12/ VType Speed regulation method: Mechanical Bore stroke: 200*210 mm Intake method: Natural inhalation Compression ratio: 13.5：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-1200 Wiring mode：Three-phase four-wire, Y-connection Generator power: 1200kW/1500kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、
A Technical parameters of diesel generator set Generator set model：HQ900GF Steady state voltage adjustment rate (%): 1 Generator power:900kW/1125kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:1620A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:4800*1500*1880 （L*W*H mm） Diesel generator fuel consumption (100% load):209g/kWh Diesel generator weight:6850kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Yuchai diesel engine Cooling method: Closed water-cooling Diesel engines model: YC6C1320L-D20 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 200*210mm Intake method: Natural inhalation Compression ratio: 14.5：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-900 Wiring mode：Three-phase four-wire, Y-connection Generator power: 900kW/1125kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Dail
A Technical parameters of diesel generator set Generator set model：HQ800GF Steady state voltage adjustment rate (%): 1 Generator power:800kW/1000kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:1440A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:4200*1500*1850 （L*W*H mm） Diesel generator fuel consumption (100% load):209g/kWh Diesel generator weight:4850kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Yuchai diesel engine Cooling method: Closed water-cooling Diesel engines model: YC6C1320L-D31 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 200*210mm Intake method: Natural inhalation Compression ratio: 14.5：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-800 Wiring mode：Three-phase four-wire, Y-connection Generator power: 800kW/1000kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Dail
A Technical parameters of diesel generator set Generator set model：HQ700GF Steady state voltage adjustment rate (%): 1 Generator power:700kW/875kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:1260A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:4200*1500*1880 （L*W*H mm） Diesel generator fuel consumption (100% load):205g/kWh Diesel generator weight:4650kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Yuchai diesel engine Cooling method: Closed water-cooling Diesel engines model: YC6C1020L-D31 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 200*210mm Intake method: Natural inhalation Compression ratio: 14.5：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-700 Wiring mode：Three-phase four-wire, Y-connection Generator power: 700kW/875kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Daily
Technical parameters of diesel generator set Generator set model：HQ500GF Steady state voltage adjustment rate (%): 1 Generator power:500kW/625kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:900A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:3400*1390*1780 （L*W*H mm） Diesel generator fuel consumption (100% load):205g/kWh Diesel generator weight:3650kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Yuchai diesel engine Cooling method: Closed water-cooling Diesel engines model: YC6T780L-D31 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 145*165 mm Intake method: Natural inhalation Compression ratio: 14：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-500 Wiring mode：Three-phase four-wire, Y-connection Generator power: 500kW/625kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Daily fuel
Technical parameters of diesel generator set Generator set model：HQ600GF Steady state voltage adjustment rate (%): 1 Generator power:600kW/750kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:1080A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:4050*1540*1920 （L*W*H mm） Diesel generator fuel consumption (100% load):210g/kWh Diesel generator weight:5200kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Diesel engines brand：Weichai engine Cooling method: Closed water-cooling Diesel engines model: 12M26D748E200 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: Mechanical Bore stroke: 150*150 mm Intake method: Natural inhalation Compression ratio: 15：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-600 Wiring mode：Three-phase four-wire, Y-connection Generator power: 600kW/750kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel)； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Daily fuel tank、
Technical parameters of diesel generator set Generator set model：HQ800GF Steady state voltage adjustment rate (%): 1 Generator power:800kW/1000kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjust
Technical parameters of diesel generator set Generator set model：HQ700GF Steady state voltage adjustment rate (%): 1 Generator power:700kW/875kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustm
