HUAQUAN - Professional Gas Generator Manufacturer

300KW YC gas generator brushless China brand engine all day running

Technical parameters of gas generator set Generator set model：HQRQ300GF Steady state voltage adjustment rate (%): 1 Generator power:300kW/375kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:540A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Gas grade:LNG/CNG/Biogas Frequency stabilization time (S):3 Gas/Biogas generator size:3000*1050*1700 （L*W*H mm） Gas /biogas generator fuel consumption (100% load):0.6g/kWh Gas/Biogas generator weight:2800kg Diesel generator volume(LP7m):95dB（A） Technical parameters of diesel engine Gas/Biogas engines brand：Yuchai gas engine Cooling method: Closed water-cooling Gas/Biogas engines model: YC6T350NL-D20 Oil supply method: direct injection Engine cylinder number: 6 / L Type Speed regulation method: ECU control Bore stroke: 145*165 mm Intake method: Natural inhalation Compression ratio: 11.5 ：1 Overload capacity: 110% Start method：DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand：Huaquan Brushless Generator Protection level：IP22 Generator Model：HQF-100 Wiring mode：Three-phase four-wire, Y-connection Generator power:100kW/125kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine( Gas/Biogas )； 2)、AC synchronous generator（Single Bearing）； 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards； 4)、Generation output air switch、Standard control panel； 5)、Steel common base with shock absorber； 6)、Dry-type air filterfuel filter，oil filter、starting motor、Self-charging alternator； 7)、starter battery and connecting cables； 8)、Industrial9dBmufflerand accessories； 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet； Optional accessories（Extra charged） 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Daily fuel tank、I
