15Kw Weichai Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ15GF 输出功率 Power Output 15kW/18.75kVA 输出电压 Voltage Output 400V/230V 输出电流 Current Output 27A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight / 开架尺寸 Open type size / 静音箱机组/重量 Static speaker unit weight / 静音尺寸： Silent type size: / 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP3.2D20E310 品牌 Brand Weichai 排量 Displacement 3.2L 柴油机额定功率 Diesel engine rated power 18kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（100%负载） Fuel Consumption（100％Load） 195g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 98105 mm 压缩比 Compression Ratio 17.2:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 9L 备用功率 Standby power 20kW 调速方式 Governor Type: Electric controlled high-pressure common rail/电控高压共轨 电机型号： Alternator Secifications Model: HQF-15 品牌 Brand Weichai 额定功率 Rated Power 15kW/18.75KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminating
75kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ75GF 输出功率 Power Output 75kW/93,75kVA 输出电压 Voltage Output 430V/230V 输出电流 Current Output 135A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1200(KG) 开架尺寸 Open type size 2100*770*1320（LWH mm） 静音箱机组/重量 Static speaker unit weight 1700(KG) 静音尺寸： Silent type size: 3000*1050*1700（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP4.1D100E200/ WP4.1D105E310 品牌 Brand WC 排量 Displacement 4.09 (L) 柴油机额定功率 Diesel engine rated power 90-96kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 105*118 (mm) 压缩比 Compression Ratio 17.5:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 13 (L) 备用功率 Standby power 100-105 (kW) 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-75 品牌 Brand Huaquan 额定功率 Rated Power 75kW/93.75kVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three emission standards ,energy saving. 6.Camel battery 2S maintenanc
120kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ120GF 输出功率 Power Output 120kW/150kVA 输出电压 Voltage Output 380V 输出电流 Current Output 216A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1200KG 开架尺寸 Open type size 2380*880*1300（LWH mm） 静音箱机组/重量 Static speaker unit weight 1800KG 静音尺寸： Silent type size: 3200*1100*1770（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） QSB5.9-G3 发动机型号： Engine Model B5.9CS4-GT1/6BTAA5.9-G2/6BTAA5.9-G12 QSB5.9-G3/QSB5.9-G31 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 129-140kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 102*120mm/ 107*124mm 压缩比 Compression Ratio 17.3:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 16-16.4L 备用功率 Standby power 130-150kW 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-120 品牌 Brand Huaquan 额定功率 Rated Power 120KW/150KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three emission standards ,energy saving.
150kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ150GF 输出功率 Power Output 150kW/187.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 270A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1500KG 开架尺寸 Open type size 2400*880*1443（LWH mm） 静音箱机组/重量 Static speaker unit weight 1900KG 静音尺寸： Silent type size: 3200*1100*1770（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） B6.7CS4-GT2 发动机型号： Engine Model 6CTA8.3-G1/6CTA8.3-G2/QSB5.9-G33 QSB6.7-G3/QSB6.7-G4/QSB6.7-G32 B6.7CS4-GT2 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 151-173kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 102*120mm/ 107*124mm/114*135mm 压缩比 Compression Ratio 17.3:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 16-28L 备用功率 Standby power 175-185kW 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-150 品牌 Brand Huaquan 额定功率 Rated Power 150KW/187.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three em
200kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ200GF 输出功率 Power Output 200kW/250kVA 输出电压 Voltage Output 380V 输出电流 Current Output 360A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2200KG 开架尺寸 Open type size 2600*950*1571（LWH mm） 静音箱机组/重量 Static speaker unit weight 2700KG 静音尺寸： Silent type size: 3800*1300*1950（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model 6LTAA8.9-G2/6LTAA8.9-G3/L9CS4-GT2 6CTAA8.3-G9/6LTAA9.5-G3/QSL8.9-G2 QSB6.7-G31/QSL8.9-G3/QSL8.9-G4 QSL8.9-G34/L9CS4-GT1/QSM11-G1 NT855-GA/NT855-G1/QSNT-G6 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 206-250kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 114*145mm/ 116.5*144.5mm/140*152mm 压缩比 Compression Ratio 16.1:1/16.4:1/16.6:1/16.7:1/17.3:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 19.5-32.4L 备用功率 Standby power 240-265kW 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-200 品牌 Brand Huaquan 额定功率 Rated Power 200KW/250KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of prec
150kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ150GF 输出功率 Power Output 150kW/187.5kVA 输出电压 Voltage Output 430V/230V 输出电流 Current Output 270A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1700 (KG) 开架尺寸 Open type size 2900*880*1500（LWH mm） 静音箱机组/重量 Static speaker unit weight 2200 (KG) 静音尺寸： Silent type size: 3200*1500*2300（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP6D167E600 / WP7D185E310 品牌 Brand WC 排量 Displacement 6.75 (L) / 7.47 (L) 柴油机额定功率 Diesel engine rated power 150kW-168kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 105*130 (mm) / / 压缩比 Compression Ratio 18.0:1/17.5:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 16 (L) /18 (L) 备用功率 Standby power 167(kW)-185 (kW) 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-150 品牌 Brand Huaquan 额定功率 Rated Power 150kW/187.5kVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three emission standards ,en
250kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ250GF 输出功率 Power Output 250kW/312.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 450A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2950KG 开架尺寸 Open type size 2950*1040*1613（LWH mm） 静音箱机组/重量 Static speaker unit weight 3500KG 静音尺寸： Silent type size: 3800*1300*1950（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model QSM11-G2/QSL8.9-G33/6LTAA9.5-G1 NT855-G1A/NT855-G1B/QSNT-G7 QSNT-G1/QSNT-G2/NT855-G2 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 264-292kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 114*145mm/ 116.5*148mm/140*152mm 压缩比 Compression Ratio 14.0:1/16.6:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 27.6-32.4L 备用功率 Standby power 291-321kW 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-250 品牌 Brand Huaquan 额定功率 Rated Power 250KW/312.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the nation
250kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ250GF 输出功率 Power Output 250kW/312.5kVA 输出电压 Voltage Output 430V/230V 输出电流 Current Output 450A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2600 (KG) 开架尺寸 Open type size 3100*884*1610（LWH mm） 静音箱机组/重量 Static speaker unit weight 3100 (KG) 静音尺寸： Silent type size: 3800*1300*1950（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP12D317E200 / WP10D320E200 WP10D320E350 品牌 Brand WC 排量 Displacement 9.73 (L)/ / 柴油机额定功率 Diesel engine rated power 288kW-291kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 126*130 (mm) / / 压缩比 Compression Ratio 17.0:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 24(L) 备用功率 Standby power 317(kW)-320(kW) 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-250 品牌 Brand Huaquan 额定功率 Rated Power 250kW/312.5kVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, higher fuel utilization, and meet the national three emission standards ,energy savin
300kW KMS Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ300GF 输出功率 Power Output 300kW/375kVA 输出电压 Voltage Output 380V 输出电流 Current Output 540A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2600KG 开架尺寸 Open type size 3200*1040*1643（LWH mm） 静音箱机组/重量 Static speaker unit weight 3600KG 静音尺寸： Silent type size: 4100*1500*2100（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） QSNT-G2 发动机型号： Engine Model QSM11-G3/QSM11-G4/QSM11-G5 QSM11-G6/6ZTAA13-G3/QSL8.9-G30 QSZ13-G6/NTA855-G2A/NTAA855-G7A NTAA855-G7/KTA19-G2/QSNT-G2 品牌 Brand KMS 排量 Displacement / 柴油机额定功率 Diesel engine rated power 300-343kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（Full Load） 195g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 114*145mm/ 130*163mm/140*152mm 压缩比 Compression Ratio 14.0:1/16.6:1/17.0:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 27.6-45.4L 备用功率 Standby power 343-380kW 调速方式 Governor Type: Electric control电子调速/ ECU电控 电机型号： Alternator Secifications Model: HQF-300 品牌 Brand Huaquan 额定功率 Rated Power 300KW/375KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 5. ECU central control unit The diesel is atomized, mixed with the air in the combustion chamber, and injected into the combustion chamber according to a certain pressure, time, and rate of fire, to achieve the effect of precise fuel injection, lower fuel consumption, hi
20kW Weichai Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ20GF 输出功率 Power Output 20kW/25kVA 输出电压 Voltage Output 400V/230V 输出电流 Current Output 36A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight / 开架尺寸 Open type size / 静音箱机组/重量 Static speaker unit weight / 静音尺寸： Silent type size: / 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP2.3D25E200 品牌 Brand Weichai 排量 Displacement 2.29L 柴油机额定功率 Diesel engine rated power 23KW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（100%负载） Fuel Consumption（100％Load） 195g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 100115 mm 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 8.5L 备用功率 Standby power 25kW 调速方式 Governor Type: machine control/机械调速 、electronic speed control/电子调速 电机型号： Alternator Secifications Model: HQF-20 品牌 Brand Weichai 额定功率 Rated Power 20kW/25kVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminating th
40kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ40GF 输出功率 Power Output 40kW/50kVA 输出电压 Voltage Output 400V/230V 输出电流 Current Output 54A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 750(kg) 开架尺寸 Open type size 1750*800*1150(mm) 静音箱机组/重量 Static speaker unit weight 1050(kg) 静音尺寸： Silent type size: 2250*1100*1570(mm) 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP2.3D4 8 E2 00 品牌 Brand WC 排量 Displacement 2.29L 柴油机额定功率 Diesel engine rated power 48kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（full load） 195g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 90100 mm 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 8L 备用功率 Standby power 48kW 调速方式 Governor Type: Electronic regulator/电子调速 电机型号： Alternator Secifications Model: HQF-20 品牌 Brand WC 额定功率 Rated Power 40kW 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 4. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 5.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 6. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the nois
50kW WC Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ50GF 输出功率 Power Output 50kW/62.5kVA 输出电压 Voltage Output 400V/230V 输出电流 Current Output 90A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 800KG 开架尺寸 Open type size 2100*790*1241（LWH mm） 静音箱机组/重量 Static speaker unit weight 1100KG 静音尺寸： Silent type size: 2550*1100*1570（LWH mm） 噪声（LP7m） Acoustic Noise（LP7m）： 95dB（A） 发动机型号： Engine Model WP4.1D66EE200 品牌 Brand WC 排量 Displacement 4.09（ L ） 柴油机额定功率 Diesel engine rated power 60kW 燃油等级（标准） Fuel Grade （Standard）0#Light Diesel/轻柴油 燃油消耗（满负载） Fuel Consumption（full load） 195g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 105118 mm 压缩比 Compression Ratio 17.5:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity 13（ L ） 备用功率 Standby power 55kW 调速方式 Governor Type: Electronic regulatorl/电子调速 电机型号： Alternator Secifications Model: HQF-50 品牌 Brand WC 额定功率 Rated Power 50kW/62.5KVA 功率因数 Power Factor COS=0.8（Lag）/滞后 额定电压 Rated Voltage 400V/230V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR（Automatic Voltage Regulator） 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Electronic regulator No need to manually adjust the throttle，The electronic regulator automatically adjusts the throttle，Stable speed, stable voltage and fuel saving. 4. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 5.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 6. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loos
