150kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ150GF 输出功率 Power Output 150kW/187.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 270A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1600KG 开架尺寸 Open type size 2600*850*1600(LWH mm) 静音箱机组/重量 Static speaker unit weight 2100KG 静音尺寸: Silent type size: 3200*1100*1770(LWH mm) 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-150L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 165KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke / 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 180KW 调速方式 Governor Type: Electric control/电子调速 电机型号: Alternator Secifications Model: HQF-150 品牌 Brand Huaquan 额定功率 Rated Power 150KW/187.50KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminatin
300kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ300GF 输出功率 Power Output 300kW/375kVA 输出电压 Voltage Output 380V 输出电流 Current Output 540A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2400KG 开架尺寸 Open type size 3100*1010*1630(LWH mm) 静音箱机组/重量 Static speaker unit weight 3400KG 静音尺寸: Silent type size: 4100*1500*2100(LWH mm) 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-300L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 323KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke / 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 355KW 调速方式 Governor Type: Electric control/电子调速 电机型号: Alternator Secifications Model: HQF-300 品牌 Brand Huaquan 额定功率 Rated Power 300KW/375KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle,The electronic regulator automatically adjusts the throttle,Stable speed, stable voltage and fuel saving. 5.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 6. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and red
250kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ250GF 输出功率 Power Output 250kW/312.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 450A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 2300KG 开架尺寸 Open type size 3000*950*1700(LWH mm) 静音箱机组/重量 Static speaker unit weight 2800KG 静音尺寸: Silent type size: 3800*1300*1950(LWH mm) 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-250L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 286KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke / 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 315KW 调速方式 Governor Type: Electric control/电子调速 电机型号: Alternator Secifications Model: HQF-250 品牌 Brand Huaquan 额定功率 Rated Power 250KW/312.5KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle,The electronic regulator automatically adjusts the throttle,Stable speed, stable voltage and fuel saving. 5.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 6. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and
200kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ200GF 输出功率 Power Output 200kW/250kVA 输出电压 Voltage Output 380V 输出电流 Current Output 360A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight / 开架尺寸 Open type size / 静音箱机组/重量 Static speaker unit weight / 静音尺寸: Silent type size: / 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-200L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 235KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke / 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 268KW 调速方式 Governor Type: Electric control/电子调速 电机型号: Alternator Secifications Model: HQF-200 品牌 Brand Huaquan 额定功率 Rated Power 200KW/250KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4. Electronic regulator No need to manually adjust the throttle,The electronic regulator automatically adjusts the throttle,Stable speed, stable voltage and fuel saving. 5.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 6. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 7. Pure copper brushles
120kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ120GF 输出功率 Power Output 120kW/150kVA 输出电压 Voltage Output 380V 输出电流 Current Output 210A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1200KG 开架尺寸 Open type size 2300*800*1380(LWH mm) 静音箱机组/重量 Static speaker unit weight 1800KG 静音尺寸: Silent type size: 3200*1100*1770(LWH mm) 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-120L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 132KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke 105135 mm 压缩比 Compression Ratio 19.0:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 145KW 调速方式 Governor Type: machine control/机械调速 电机型号: Alternator Secifications Model: HQF-120 品牌 Brand Huaquan 额定功率 Rated Power 40KW/50KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, elimi
100kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ100GF 输出功率 Power Output 100kW/125kVA 输出电压 Voltage Output 380V 输出电流 Current Output 180A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1200KG 开架尺寸 Open type size 2300*800*1380(LWH mm) 静音箱机组/重量 Static speaker unit weight 1600KG 静音尺寸: Silent type size: 3000*1050*1700(LWH mm) 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-100L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 110KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke / 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 121KW 调速方式 Governor Type: machine control/机械调速 电机型号: Alternator Secifications Model: HQF-100 品牌 Brand Huaquan 额定功率 Rated Power 100KW/125KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminating the
75kW Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ75GF 输出功率 Power Output 75kW/93.75kVA 输出电压 Voltage Output 380V 输出电流 Current Output 135A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 1100KG 开架尺寸 Open type size 2100*800*1300(LWH mm) 静音箱机组/重量 Static speaker unit weight 1500KG 静音尺寸: Silent type size: 3000*1500*2280(LWH mm) 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-75L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 84KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 6/L Type 缸径*行程 Bore and Stroke / 压缩比 Compression Ratio / 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 92KW 调速方式 Governor Type: machine control/机械调速 电机型号: Alternator Secifications Model: HQF-75 品牌 Brand Huaquan 额定功率 Rated Power 75KW/93.75KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminating the shor
50Kw Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ50GF 输出功率 Power Output 50kW/62.5kVA 输出电压 Voltage Output 380V 输出电流 Current Output 90A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 800KG 开架尺寸 Open type size 1800*750*1300(LWH mm) 静音箱机组/重量 Static speaker unit weight 1200KG 静音尺寸: Silent type size: 2550*1100*1570(LWH mm) 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-50L 品牌 Brand Huaquan 排量 Displacement / 柴油机额定功率 Diesel engine rated power 56KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 105125 mm 压缩比 Compression Ratio 19.0:1 启动方式 Starting System DC24V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 62KW 调速方式 Governor Type: machine control/机械调速 电机型号: Alternator Secifications Model: HQF-50 品牌 Brand Huaquan 额定功率 Rated Power 50KW/62.5KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminating
40Kw Weifang Diesel Generator Technical Data 机组规格型号 GenSets Specifications HQ40GF 输出功率 Power Output 40kW/50kVA 输出电压 Voltage Output 380V 输出电流 Current Output 72A 额定频率 Rated Frequency 50Hz 额定转速 Rated Speed 1500rpm 开架机组/重量 Open frame unit weight 700KG 开架尺寸 Open type size 1750*750*1300(LWH mm) 静音箱机组/重量 Static speaker unit weight 1000KG 静音尺寸: Silent type size: 2550*1100*1570(LWH mm) 噪声(LP7m) Acoustic Noise(LP7m): 95dB(A) 发动机型号: Engine Model HD-40L 品牌 Brand Weifang 排量 Displacement / 柴油机额定功率 Diesel engine rated power 42KW 燃油等级(标准) Fuel Grade (Standard)0#Light Diesel/轻柴油 燃油消耗(100%负载) Fuel Consumption(100%Load) 205g/kWh 气缸 Cylinder 4/L Type 缸径*行程 Bore and Stroke 100115 mm 压缩比 Compression Ratio 19.0:1 启动方式 Starting System DC12V Electric/电启动 润滑油容量 Lube Capacity / 备用功率 Standby power 46KW 调速方式 Governor Type: machine control/机械调速 电机型号: Alternator Secifications Model: HQF-40 品牌 Brand Huaquan 额定功率 Rated Power 40KW/50KVA 功率因数 Power Factor COS=0.8(Lag)/滞后 额定电压 Rated Voltage 380V 绝缘等级 Insulation Class H 过载能力 Over Capacity 110% 转速 Speed(RPM) 1500 防护等级 Indicating of Protection IP22 接线方式 Wiring Mode 3Phase 4Wires Y Type 调节方式 Governor AVR(Automatic Voltage Regulator) 2. High pressure oil pump The fuel injection pump is one of the main components of the engine Huaquan engine mainly uses Wuxi Weifu oil pump、 Beijing Tianwei Oil Pump、Longkou Steyr Oil Pump、 Nanyue Hengyang oil pump and so on. 3. Cooling water tank Closed water tank, high heat dissipation efficiency Cooling protection, integrated design 4.Camel battery 2S maintenance-free series Low self-discharge rate -30℃ low temperature start Good electrical conductivity Improved starting power Strong power and long life high strength 5. Damping block Adopt rubber car type shock absorber to reduce the vibration of the unit, reduce the damage to the parts and prolong the service life of the unit. The double screw design is stable and more durable, and prevents loosening during operation, and reduces the noise caused by vibration . 6. Pure copper brushless motor Strong power and lengthened silicon core Pure copper brushless motor Stronger conductivity, eliminating the
Technical parameters of diesel generator set Generator set model:HQ50GF Steady state voltage adjustment rate (%): 1 Generator power:50kW/62.5kVA Voltage fluctuation rate (%): 0.5 Power factor:COS = 0.8 (lagging) Transient voltage adjustment rate (%):+20 ~-15 Output voltage:400V/230V Voltage stabilization time (s):1 Generator set current:90A Steady state frequency adjustment rate (%): 1 Rated frequency:50Hz Frequency fluctuation rate (%): 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):3 Diesel generator size:1800*750*1300 (L*W*H mm) Diesel generator fuel consumption (100% load):224g/kWh Diesel generator weight:800kg Diesel generator volume(LP7m):95dB(A) Technical parameters of diesel engine Diesel engines brand:Ricardo engine Cooling method: Closed water-cooling Diesel engines model: ZH4100D Oil supply method: direct injection Engine cylinder number: 4 / L Type Speed regulation method: Mechanical Bore stroke: 105*125 mm Intake method: Natural inhalation Compression ratio: 19:1 Overload capacity: 110% Start method:DC 12V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Generator brand:Huaquan Brushless Generator Protection level:IP22 Generator Model:HQF-50 Wiring mode:Three-phase four-wire, Y-connection Generator power:50kW/62.5kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COS = 0.8 (lag) Genset standard features 1)、Direct injection internal combustion engine(Diesel); 2)、AC synchronous generator(Single Bearing); 3)、Water Radiatordesign for 40-45℃ Ambient belt-driven fans and guards; 4)、Generation output air switch、Standard control panel; 5)、Steel common base with shock absorber; 6)、Dry-type air filterfuel filter,oil filter、starting motor、Self-charging alternator; 7)、starter battery and connecting cables; 8)、Industrial9dBmufflerand accessories; 9)、The engine and alternators original technical papers,manuals and testing reports ship with GenSet; Optional accessories(Extra charged) 1)、Engine oil、diesel、water jacket、Anti-condensation heater 2)、Battery floating charger 3)、Self-protection unit/self-starting control panel 4)、Tree-remote control panel 5)、ATS AUTO-loadedtransferringscreen 6)、Daily fuel tank、Integralfu
